The second generation of W-band super conducting magnet features a horizontal field, a main coil with 6 T sweep range, permanent leads and a 2 kG high resolution sweep coil. There are currently two W-band systems, the E600 and E680. The former is optimized for CW-EPR experiments at 94 GHz, while the E680 operates in both CW- and FT-mode. These high-class research instruments provide a maximum in performance and flexibility while still being easy to operate.

Main parameters:

• Precise microwave power setting over a 60 dB range in W-band

• All FT-EPR relevant parameters such as pulse power, width and phase are set and monitored on the intermediate frequency (IF) at X-band

• High spectral purity, and sensitivity, are achieved by the combination of a fixed frequency oscillator and a PLL circuit

Main parameters:

• 24 bit center field resolution, corresponding to a precision of < 10^-7 mT 24 bit signal digitization

• Up to 256,000 points for field sweep

• Full freedom in magnetic field sweep from 100 mG up to the maximum field

• Independent of conversion time, large and small signals can be detected with one gain setting

• Dual channel, simultaneous detection of 1st and 2nd harmonic (or 0° and 90° modulation phase)

• Sensitivity up to 2000:1 (International Weak-Pitch Protocol) with PremiumX

• Easy upgrade to multi-frequency CW-EPR from L-band to Q-band

• CW-ENDOR for the first time in this spectrometer class

• Range of accessories and dedicated resonators

Main parameters:

• 263 GHz operation frequency (J-Band)

• Quasi optical front end

• Reflection and induction mode

• CW and FT operation

• ELDOR channel

• 20 mW power

• Single mode resonator

• Non-resonant probe

• Sample temperature: 4 - 300 K

• Cryogen-free magnet

• 12 T main coil

• 0.2 T sweep coil

Main parameters:

• Operating frequencies - 9.5 GHz (X-band) and 35 GHz (Q-band)

• Microwave power - 200 mW max

• Scan range - 0 - 2 T

• Modulation amplitude - 4.0 mT max

• Gain - 10⁵ max

• First and second derivative plotting

• Broad-line analysis

Main parameters:

• Operating frequency - X-Band

• Microwave power: - 100 mW

• Concentration sensitivity - 50 pM

• Field sweep range - 7000 G

• Field homogeneity - 50 mG over sample volume

• Field stability - 10 mG/h

• Sweep resolution (field and time) - 250.000 points

• Reference standard - Integrated and motorized

• SpinCount - Concentration determination

• SpinFit - Spectrum simulation and fitting for isotropic and anisotropic data

The X-band 8400 EPR spectrometer is a completely self-contained instrument, incorporating a microwave Gunn oscillator, microwave bridge apparatus (circulator, reference arm, etc.), a type TE₁₀₂ microwave cavity, lock-in amplifier circuitry, field controller, electromagnet and power supply in one table-top sized cabinet operating under control of a personal computer. Its compact electromagnet and power supply result in the spectrometer's desktop size. This along with its ability to operate in the absence of water lines for cooling, means that the 8400 is truly portable. Its automated features make it easy to use and easy to learn to use.

Main parameters:

• Frequency - 9.1 - 9.6 GHz

• Microwave power - 100 mW min (200 mW at 9.4 GHz)

• Sensitivity - 5x10⁶ spins/G (5x10¹⁰ spins/T)

• Magnetic field strength - 100 - 7000 G (0.01 - 0.7 T) at homogeneity 10^-5

• Resolution - 0.07 G/cm (7 μT/cm)

• Cavity Resonantor mode - TE₁₀₂

• Cavity Resonantor unloaded Q-factor - 5000

• Polepiece gap - 14 mm

• Field uniformity - 0.01 G/cm³ (1 μT/cm³)

• Field stability - 1x10^-5 hour^-1

• Modulation frequency - 100 kHz

• Modulation amplitude - 10 G (1 mT) max

• Field setting resolution - 1 G (0.1 mT)

• Sweep time - 30 - 3600 s with 12-bits resolution

• Sample tube ∅ - 5 mm

• Sample temperature range - 25 - 45 °C thermostated with 0.5 °C accuracy

• Dimensions - 262×483×457 mm

• Weight - 50 kg

• Power - single phase, 500 VA, 110/220/240 VAC, 50/60 Hz, 3A

• Cooling - not required below 4000 G (400 mT); 0.25 water liter/min otherwise

• Operation temperature - 10 - 50 °C

• Computer OS - MS Windows

The Benchtop Micro-ESR™ includes our patented miniature electron spin resonance spectrometer, operating either 3.4 GHz or 9.6 GHz with a sweep range from g=1.8 to g=2.2 and sub-micromolar sensitivity in aqueous solution. Also included are a full Windows XP computer system, integrated touchscreen, Ethernet and multiple USB ports.

Main parameters:

eScan device is suitable for specific quality control applications as well as for medical and pharmaceutical R&D applications.

Main parameters:

• Research grade sensitivity

• Predefined acquisition schemes

• Fully automatic data evaluation

• User level security

• Automatic instrument validation and system data logging

• Easy to learn windows TM software

Main parameters:

• Magnetic field range - from 0.01 T to 0.7 T at homogeneity 10^-5

• Sensitivity - 10⁺¹⁵ spin/T

• Microwave power - 200 mW at 9.4 GHz

• Sample temperature range - from 25 to 45 °C, thermostated at 0.5 °C accuracy

• Automatic tuning of the spectrometric system for each sample

• Registration and processing of ESR spectra under computer control

• High stability and noise-immunity of measured spectra

• Dimensions - 240×600×600 mm

• Weight - 60 kg

Main parameters:

• Operating frequency - 9.72 GHz

• Sensitivity - 4×10¹⁰ spins/0.1 mT

• Resonance instability - 3×10^-5 h^-1

• Polarizing magnetic field induction - 0 - 0.7 T

• Error of magnetic field setting - 1% max

• Period of magnetic field scanning - 30 sec min

• Amplification region - 1 - 1.6×10⁵

• Microwave power in cavity - 150 mW max

• Frequency of magnetic field modulation - 100 kHz

• Region of magnetic field modulation - 2×10^-3 - 1.0 mT

• Cavity mode - H₁₀₂

• Unloaded cavity Q-factor - 5000

• Inner sample diameter - 10 mm

• Power supply - 230 V AC

• Interface - RS232

• Dimensions - 480 (W) × 200 (H) × 475 (D) mm³

• Weight - 60 kg

Main parameters:

• Operating frequency - 9.1 - 9.5 GHz

• Sensitivity - 5×10¹⁰ spins/0.1 mT

• Magnetic field homogeneity - 3×10^-5 mT

• Resonance instability - 3×10^-5 h^-1

• Polarizing magnetic field induction - 0.01 - 0.8 T

• Spectral resolution - 3×10^-5

• Frequency of magnetic field modulation - 100 kHz

• Microwave power in cavity - 200 mW max

• Cavity mode - H₁₀₂

• Inner sample diameter - 11 mm

• Interface - RS232, USB

• Power supply - 400 W AC

• Dimensions - 460 (W) × 300 (H) × 460 (D) mm³

• Weight - 65 kg

Main parameters:

• Working frequency range - 9.0 - 9.6 GHz

• Sensitivity - 2×10¹⁰ spin/0.1 mT

• Microwave power in a cavity - 100 mW max

• Modulation frequency - 100 MHz

• Modulation amplitude of magnetic field - 0.01 - 1 mT

• Setting discretness of magnetic field - 0.1 mT

• Magnetic field change region - 0.1 mT - 0.45 T

• Stability of magnetic field - 10^-5

• Frequency stability of MW oscillator - 10^-6

• Stability of resonance conditions - 2×10^-5

• Sample diameter - 11 mm max

• Device dimensions - 700×500×400 mm³

• Power supply - 500 AV

• Weight - 95 kg

Main parameters:

• Operating frequency - 9.30 - 9.55 GHz

• Sensitivity - 8×10⁹ spins/0.1 mT

• Microwave power in cavity - 50 mW max

• Cavity mode - H₁₀₂

• Frequency of magnetic field modulation - 100 kHz

• Polarizing magnetic field induction - 0 - 0.55 T

• Magnetic field stability - 2 µT

• Magnetic field homogeneity - ± 5 µT

• Magnetic field range - 50 - 450 mT

• Modulation amplitude - 2 µT - 0.7 mT

• Sweep time - 0.2 - 34 min

• Outer sample diameter - 3 - 6 mm

• Interface - RS232, USB

• Dimensions - 530 (W) × 360 (H) × 420 (D) mm³

• Power supply - 500 W AC

• Weight - 60 kg

Main parameters:

• Working frequeny - 9.3 - 9.6 GHz

• Microwave power in a cavity - 100 mW max

• Magnetic field induction - 3000 - 4000 Gauss

• Distance between magnet poles - 22.5 mm

• Diameter of the poles' tips - 90 mm

• Period of the magnetic field retuning - 0.5 - 64 minutes

• Sensitivity - 5x10^-12 diphenylpicrilhedrosyl mole

• Stability of resonance conditions - 2×10^-5 per hour max

• Interface - RS232C

• Expluatation conditions - 10 - 45 °Ñ.

• Power supply - 220 V, 50 Hz

From the site www.fizepr.ru

Main parameters:

• Operating frequency - 3.4 GHz

• Magnet assembly - 118 mT ± 13.5 mT

• Magnetic field uniformity - 0.01 mT

• G-factor range - 1.8 - 2.2

• Sensitivity limit - 0.5 μM (aqu. solution)

• Minimum sample size - 25 μL

• Automatic temperature controller

• Interface - Ethernet, 802.11 wireless and USB

• Sample diameter - 2.4 mm

• Power supply - 15 VDC / 5.0A (120V/240V)

• Dimensions - 20x18x13 cm (8x7x5 inch)

Main parameters:

• Operating frequency - 9.35 GHz

• Microwave power - 1.0 mW

• Permanent magnetic field - 1.32 T

• Region of magnetic field sweeping - 0 - 20 mT

• Magnetic field modulation - 0.02 - 0.2 mT

• Modulation frequency - 33 kHz

• Sensitivity - 10¹⁴ spins/0.1 mT

• Cavity mode - H₁₀₂

• Unloaded cavity Q-factor - 4000

• Sample diameter - 4 mm

• Accumulation number - 1 - 255

• Interface - RS232

• Power supply - +12 V DC or 230 V AC

Main parameters:

• Short-circuit MW piston adjusting range - 30 mm

• Sample - tube (Ø2 x 6 mm) with DPPH powder

• MW frequency measurement range - 8.6 - 9.6 GHz

• Waveguide inner dimensions - 22.86 x 10.16 mm

• Magnetic field sourcer out - ≥20 V, 0 - 2.5 A, 1% ± 1 digit

• Sweep field signal output - ≥6 V, 0.2 - 0.7 A

• Stability - ≤1x10^-3 + 5 mA

• MW solid state source frequency - 8.6 - 9.6 GHz

• MW frequency drift - ≤± 5x10^-4/15 min

• MW source output power - > 20 mW

• Phase adjustment range - ≥180°

• Modulation frequency - 1000 ± 15% Hz

• Voltage standing wave ratio - < 1.2
